Name: AQ2000-01, AQ2000-02, AQ3000-02 SMC AQ Series Quick Exhaust Valve 1/8", 1/4", 3/8", 1/2", 3/4"
Brand: Airwolf Automation
SKU: AQ2000-01، AQ2000-02، AQ3000-02، AQ3000-03، AQ5000-04، AQ5000-06
Price: 5.00 USD
Availability: InStock

خانه محصولات دریچه های کنترل جریان هوا

AQ2000-01, AQ2000-02, AQ3000-02 SMC AQ Series Quick Exhaust Valve 1/8", 1/4", 3/8", 1/2", 3/4"

جزئیات محصول:

محل منبع:	ژاپن، چین
نام تجاری:	SMC, AIRWOLF or OEM
شماره مدل:	AQ2000-01، AQ2000-02، AQ3000-02، AQ3000-03، AQ5000-04، AQ5000-06

پرداخت:

مقدار حداقل تعداد سفارش:	1 قطعه
قیمت:	5-6USD
جزئیات بسته بندی:	جعبه، کارتن، پالت، کیسه های پلاستیکی
زمان تحویل:	1-7 روز کاری
شرایط پرداخت:	T/T، وسترن یونیون، پی پال
قابلیت ارائه:	1000 قطعه در هفته

مخاطب

توضیحات محصول جزئیات

کد مورد:	AQ2000-01، AQ2000-02، AQ3000-02	مواد:	آلومینیوم دایکاست
فشار عملیاتی:	0.05 ~ 1.0MPa	دامنه دمای کار:	–5~+60℃ (بدون یخ زدگی)
اندازه بندر:	1/8، 1/4، 3/8، 1/2، 3/4 اینچ	تابع:	کنترل سرعت
برجسته کردن:	SMC AQ Series quick exhaust valve,aluminum die-cast air flow valve,quick exhaust valve with 1MPa pressure , aluminum die-cast air flow valve , quick exhaust valve with 1MPa pressure

AQ2000-01 AQ2000-02 AQ3000-02 SMC AQ Series Quick Exhaust Valve 1/8", 1/4", 3/8", 1/2", 3/4"

The SMC AQ Series Quick Exhaust Valve is designed to significantly increase the speed of pneumatic actuators, particularly cylinders, by providing a direct path for exhaust air. It is typically installed between the directional control valve and the cylinder. When the control valve is deactivated, the quick exhaust valve closes the inlet from the control valve and opens a direct path from the cylinder to the atmosphere, allowing air to escape rapidly without traveling back through the longer piping to the control valve. This setup is especially effective when the distance between the cylinder and the main control valve is long, as it shortens the exhaust path, reduces cycling time, and improves overall equipment efficiency. The valve operates with three ports (P: pressure supply, A: output to actuator, T: exhaust to atmosphere) and functions automatically based on pressure differentials.

Order Codes:

Item Code	Port Size
AQ2000-01	1/8"
AQ2000-02	1/4"
AQ3000-02	1/4"

Symbol:

AQ2000-01, AQ2000-02, AQ3000-02 SMC AQ Series Quick Exhaust Valve 1/8", 1/4", 3/8", 1/2", 3/4"

Specifications:

Model	Port size	Operating Pressure	Ambient and fluid temperature	Sonic conductance dm3/(s-bar)		Critical pressure ratio		Weight (g)
				IN→OUT	OUT→EXH	IN→OUT	OUT→EXH
AQ2000-01	1/8	0.05-1MPa	-5 to 60°C(No freezing)	5	5	0.45	0.35	110
AQ2000-02	1/4			7	8			105
AQ3000-02	1/4			8	8.4			215

Construction:

Dimensions:

Quality Standards:

The company for the products are brand new original products, no second-hand and refurbished products, or leave a compensable ten and return the full amount , but the buyer due to our purchase of model error is not responsible for returns, another of the company's sales of products enjoy one year from the date of shipment quality assurance , according to the original quality standards , during warranty with product problems , need confirmation testing by the manufacturer , the supplier to be solved , the demand side due to storage , use, poor maintenance caused by lower-quality product , and not raise objections.

Samples:

You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.

After-sale service:

We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
